Compressed Air Dryer for Plasma Cutters - AT1000
Compressed Air Dryer for Plasma Cutters - AT1000
Compressed Air Dryer for Plasma Cutters - AT1000
High quality air cleaning / drying filter assy, ideal for Plasma Cutters
  • When used with Plasma Cutters ensures long tip life and trouble free operation
  • The filter removes all oil sprays, smoke, traces of humidity and polluting particles that might not be filtered by conventional equipment
  • It is the perfect solution to problems caused by compressed air contamination.
  • Prolongs the life of equipment with a consequent reduction in maintenance costs
  • Ideal for industrial paintwork, bodyshop, tyre repairer, pneumatic tools, pneumatic equipment
  • For Ultra Clean Dry Compressed Air
  • Sub mi-cronic filtration
  • Fitted with 1/4 NPT female inlet and outlet
  • Comes with 2 x 1/4 NPT male to 1/4 BSP male adaptors
  • The AT1000 can filter up to 1250 litres/minute without any pressure reduction
  • Degree of filtration .01µinch – 0.25µm



Technical Data
Degree of filtration .01µinch – 0.25µm
Max operating pressure 125 PSI – 8.5 bar
Max output @80% 2700 SCFH 1250 l/min
Operating temperature 15-140 F -10 / +60 C°
Connection dimensions ¼ NPT
Dimensions Ø 5.2” x 7.9”
Ø 132 x 200 mm

FILTER

Dimensions: 44x30xh47

CARTRIDGE
Dimensions: 66x44xh25




View File
AT1000 Air FIlter Specification Sheet
Download
View File
AT1000 Installation Instructions Manual
Download
