5mm Max Weld
-
This is maximum weld with 1 pass, if you do multiple passes you can weld up to 10mm
-
Weld Steel
-
Welds ALL steels in DC mode, will also weld brass, copper & titanium
- Description
-
Details
The R-Tech TIG160PD-D 160Amp DC TIG welder 240V with digital panel and 9 memory store, HF starting, fully featured pulse welding, slope up/down, 2/4 way control, LED display, high 35% duty cycle and remote foot pedal options suitable for welding all steels, Ideal for pipework, fabrication and jobs where fine control is required.- Built with class leading Siemens IGBT's - Not inferior Mosfets
- See our TIG welders in action - View our how to TIG Weld videos
- Have a question about TIG welding? See our TIG Welding FAQs
- Professional Ultra Flex Torch - Flexible head and ultra flexible cable & sheath
- Mircostart HF - improved arc starting and less interference - What is this?Ensures an ultra-clean start to your welds
- Digital control panel - designed for easy use
- Full 4-way functioning with control of pre/post flow gas, initial/final amps, slope up/down
- Low starting amperage, Ideal for thin and thick materials
- Highly efficient Inverter technology - lightweight and power efficient
- 9 Memory store function - Easily program your jobs into memory
- Amperage Range TIG: 5 to 160 Amps
- Amperage Range MMA: 10 to 130 Amps
- Suitable plug required - see related products below
- 3 year collect and return UK warranty - What is this?in the unlikely event of machine failure, R-Tech will pay to collect, repair and return the Tig welder to you quickly- No quibble warranty
- Tech Specs
-
Details
Amperage range 240V DC TIG 5-160A, MMA 10-130A Duty cycle TIG 160A 35% - MMA 130A 35% Input voltage/amps 240v 13A - No load voltage 70v LED Display Shows preset & actual amperage Pulse amperage 5 - 95 % Pulse width 5 - 95 % Pulse frequency 0.5 - 500 Hz Slope up 0 - 25 seconds Slope down 0 - 25 seconds Post flow gas 0 - 25 seconds Pre flow gas 0 - 10 seconds - Ideal for stainless purging HF Start Yes 2T/4T Trigger Yes Memory store Yes - 9 MMA Arc Force Yes 1 -100 % MMA Anti Stick Yes MMA Hot start time 0.1 - 1.5 seconds MMA Hot start amps 1 - 100A Gross weight 14KG Dimensions 425 x 195 x 310 Foot pedal option Yes Insulation class IP21S Cooling fan Yes - Cooling fan with thermostatic protection Max Thickness 5MM Single Pass Max Thickness Steel 10MM Multiple Passes - Digital control panel - designed for easy use
- Control all parameters from a single button
- Easy start and finish set-up - 9 Memory store function - Easily program your jobs into memory
- 3 year collect and return UK warranty - What is this?in the unlikely event of machine failure, R-Tech will pay to collect, repair and return the Tig welder to you quickly- No quibble warranty
- Generator Friendly - Generator must be minimum of 5KVA 240V and fitted with AVR (auto voltage regulation)
- Package Includes, R-Tech TIG160PD Digital DC Tig Welder, 4M WP17 Air Cooled Tig Torch, Earth Lead, MMA Lead, Gas Hose, Mains Cable, Argon Regulator, Owners Manual, Torch Consumables Kit including Tungstens
- Digital control panel - designed for easy use
- Videos
-
Details
- Warranty
-
Details
The R-Tech TIG160PD-D carries the following warranty:-
- TIG160PD-D - 3 Year Warranty
- Regulator - 1 Year Warranty
- R-Tech TIG Torches - 3 Month Warranty
- Earth and Electrode Leads - 3 Month Warranty
- FP7 Foot Pedal - 1 Year Warranty
- Optional Water Cooler - 3 Year Warranty
R-Tech machines are designed to be robust, easy to use and highly reliable but in the unlikely event that your welder or plasma cutter requires attention, R-Tech promise to:-
- Arrange collection via next working day UK courier [48hr offshore]
- Quickly repair the machine at our Technical and R&D centre in Gloucester
- Deliver back via next working day UK courier [48hr offshore]
- All costs covered by R-Tech - Yes, Collection, repair and delivery!
No questions, no hassle, just honest and reliable service - A true no quibble warranty
Most of our competitors only offer return to base [RTB] warranties - you have to pay and arrange to get it back to them which can be a hassle. Many others offer warranties that have clauses and if you don't have it serviced yearly by them, at your cost, the warranty will be void.
Other benefits of owning an R-Tech machine include:-
- Free friendly and knowledgeable technical advice via phone and email
- Free machine setup help always available - We want you to get the best from your machine
- Ten year Duty-of-Care on all our machines, giving you piece of mind that spare parts will be available if needed
- Video's to show how to use and setup your R-Tech machine.
- 2 year extended warranties available at a minimal cost.
Don't just take our word for it - see our customer reviews page to see what real customers say about the R-Tech products and our service & support.
- Downloads
-
- Reviews
-
Product reviews for R-Tech TIG Welder DC Digital 160 Amp 240v (25)Powered by
Calculated from 25 reviews5 out of 25 reviews :18.12.2019 15:20So far so good, but still early days
02.12.2019 15:27as previously stated.
26.11.2019 19:23Purchased to get back into TIG welding after some years off, intending to practice and aid my 'SEAMLESS' return to the profession. Years back I did some City and Guilds quals using a few RTech inverters and liked them from the get go. If they are reliable enough for a school, they should be good for me! It is certainly more than enough of a machine for my needs at this moment in time, 160A seems true enough and the ability to store pre-sets is brill. HF and Lift start both work better than expected for a 'cheaper' unit. The torch is actually quite comfortable too (and a much higher quality than it looks on picture!). My only gripe is that the internal cooling fan is constantly on, not on demand. However, this does not affect performance! Great compact DC welder that you can take almost anywhere. (if you have a small enough gas bottle). Oh, and in case you don't, it stick welds pretty good too!
16.11.2019 17:39I am a model engineer building a stainless steel 7 1/4 live steam locomotive. Have not yet used the machine but would recommend the service provided. The quality of the product seems to be first class
15.05.2019 09:03excellent
