TIG Welder 240V DC 200amp

[Welding Equipment > Tig Welder > TIG Welder R-Tech Tig200PDC]

TIG Welder 240V DC 200amp

• 200Amp TIG Welding Output @ 60% Duty Cycle (?)Perfect for continuous use applications, works harder for longer
• 160Amp TIG Welding Output @ 100% Duty Cycle
• 160Amp MMA Welding Output @ 35% Duty Cycle (?)Use as a stick (Arc) welder too
• 100Amp MMA Welding Output @ 100% Duty Cycle
• 240V Single Phase Input - 22A Input 5.3KVA
• Full Featured Professional Pulse Tig welding Inc Frequency, Width and Amperage
• HF-Start (?)Instant Arc at the press of a button - get a clean start every time
• Slope up 0 - 5 Seconds (?)Gradual increase in power at the start of the weld - improves overall finishing
• Slope down 0 - 5 Seconds (?)Gradual decrease in power at the end of the weld - improves overall finishing
• Pulse Frequency range 0.5Hz - 25Hz
• Pulse Width 0.1 - 0.9 Seconds
• Pulse Amperage 5 - 200 amps
• Gas post flow 1 -10 Seconds
• 2T/4T Trigger Operation (trigger latching)
• Industrial quality metal chassis
• L.E.D Amperage Display (actual not preset)
• Remote foot pedal option for the ultimate weld pool control
• Cooling fan with thermostatic protection
• Nett Weight 18KG - Dimensions (mm) 425x195x310
• Generator Friendly - Generator must be minimum of 8KVA and fitted with AVR (auto voltage regulation)
• Package Includes, R-Tech Tig200PDC TIG welder, 4m WP26 TIG torch, earth lead, MMA Lead, gas hose, mains cable, argon regulator, owners manual, torch consumables kit including tungsten's
• 2 Year RTB parts and labour warranty
• See our range of Tig Welding Consumables
• See the Remote Foot Pedal
• View this Tig Welder Tig200PDC Owners Manual
• Download printable Tig Welder Data Sheet
• Information on the component parts of the torch
