PROTECTOVAC FUME EXTRACTOR 230V

ProtectoVac is a portable, twin-motor, high-vacuum fume-extraction system specifically designed to extract and filter metal particulate fumes created in welding processes. A high efficiency 3 stage filtration system, including a spark arrestor and is quite operation <70dBA.

The ProtectoVac is supplied with a 2.5m hose, magnetic foot welding nozzle and spare set of motor brushes, The ProtectoVac features an auto on/off function which allows the unit to be engaged automatically with the welding arc. The ProtectoVac can also be used for on-MIG-torch extraction, with the appropriate fitting kit available separately. The ProtectoVac is highly portable weighing only 15kg and mounted on swivel castors. Operates from a 230v input supply.

The ProtectoVac should NOT be used for filtering fumes containing oil, solvent, explosive dusts/gases or hybrid mixtures of wastes, etc.

Technical Specifications

Details

Extraction Capacity
Pos 1 : 160 m3/h
Pos 2 : 230 m3/h


Filter Efficiency
99.9%


Motor Power
2x 1kW


Noise Level (nozzle installed)
Pos 1 : 63 dB(A)
Pos 2 : 70 dB(A)


Weight
15 kg


Dimensions
730mm x 360mm x 360mm
